Indoor LED Display Screen with 7680Hz High Refresh Rate Front Maintenance Design and Lightweight Construction for Quick Wall Installation

Quality Indoor LED Display Screen with 7680Hz High Refresh Rate Front Maintenance Design and Lightweight Construction for Quick Wall Installation wholesale

Brand Name : GCL

Model Number : P1.953mm\P2.6mm

Certification : CE/ROHS/EMC/TUV/UL/CCC/FCC/ISO

Place of Origin : China

MOQ : 20

Price : Negotiable

Payment Terms : T/T

Supply Ability : depend on quantity

Delivery Time : 7-21days

Packaging Details : wooden case

Refresh Rate : 7680HZ

Protection Class : Front IP68, Back IP65, B1 Fireproof

Material : Aluminum Die-Casting

Pixelpitch : Variable (e.g., 1.5\1.953mm)

Colors : 281trillion

Lifespan : ≥100,000 hours

Materials : magnesium alloy

Maintenance Way : Front/Rear

Working Humidity : 10%-90%RH

Scanning Mode : 1/2

Weight : 22kgs/square meter

Refresh Frequency : 3840-7680Hz

Led Type : SMD1010 SMD1515

Working Voltage : 100V /240V

Cabinet Dimension : 1000X250mm 750*250mm LED cabinet

Contact Now

Indoor High-definition LED Display Screen P1.953, P2.6mm

Professional indoor LED video wall display designed for quick wall installation with exceptional visual performance and maintenance efficiency.

Key Features

Ultra High Definition Display: 7680Hz high refresh rate technology reduces screen flicker and delivers smoother visuals with exceptional clarity and fine picture detail reproduction.
100% Front Maintenance Design: All modules, power supplies, and accessories can be removed from the front. Magnetic suction module design enables quick and effortless servicing.
Flexible Splicing Options: Available in two box sizes (750*250mm and 1000*250mm) with 250*250mm modules for free combination and assembly to fit various installation requirements.
Hard Link Hidden Design: Top and bottom hard link signal source interfaces provide seamless connections, eliminating messy cables and ensuring clean, professional installations.
Lightweight Construction: Die-cast aluminum boxes weigh only 4.2-5.5kg with a slim 38mm profile. Enables wall mounting without structural support.
Wall Mount Installation: Steel-free frame structure with built-in connecting pieces and wall screws between boxes. Easy wall mounting without requiring additional steel framework.

Main Usage Scenarios

Indoor video wall displays
Multifunctional conference room display screens
Monitoring center display screens
Indoor advertising screens

Indoor LED Display Screen with 7680Hz High Refresh Rate Front Maintenance Design and Lightweight Construction for Quick Wall Installation

Product Specifications

Parameter	P1.5	P1.9	P2.6
Pixel Pitch (mm)	1.5625	1.953	2.604
Pixel Density (/m²)	409,600	262,144	147,456
LED Model	SMD1010	SMD1515	SMD1515
White Balance Brightness (cd/m²)	1000	1000	1000
Scanning	1/40	1/32	1/24
Cabinet Size (mm)		100025038 / 75025038
Module Size (mm)		2502503
Cabinet Material		Die-cast Aluminum
Cabinet Weight		4.2kg / 5.5kg
Protection Level		IP31
Maintenance Method		Front Maintenance
Max Power Consumption (/m²)		600W
Avg. Power Consumption (/m²)		150W
Refresh Rate		3840-7680Hz
Grayscale Level		13-16bit
Viewing Angle		H140°, V140°
Input Voltage		AC100~240V (50-60Hz)
Operating Temperature		-20℃~+60℃
